In terms of raw material proportioning and process output, PUR products employ the globally advanced six component online automatic (SIMENS) mixing and pouring technology and have realized six-component continuous foaming for the first time. With this technology, mixing and proportioning processes may be finished in an online way; the formula may be adjusted according to environmental changes; air feeding and mixing devices may be used to make raw material mixing more even and foam finer, thus producing high-strength, energy-saving and environment-friendly building boards.
Polyisocyanurate is called PIR for short. For the composite boards developed, excessive isocyanurate is added and ring structure and higher isocyanurate index are employed in the compounds to form compact PIR products, thus ensuring greater stability and excellent heat and fire resistance for the internal rigid foams. Experiments show that the products can endure temperatures up to 200ºC in short time periods or to 160ºC for long time periods.
| Allowable vertical load and thermal performance of polyurethane sandwich wall panel (allowable deflection f≤L/200) | ||||||||
|---|---|---|---|---|---|---|---|---|
| S(mm) | W/m2k | G(kg) | P=KN/m2 | 0.60 | 0.80 | 1.00 | 1.20 | 1.50 |
| 50 | 0.31 | 10.06 | L(m) | 3.52 | 3.04 | 2.69 | 2.42 | 2.11 |
| 75 | 0.21 | 11.06 | L(m) | 4.71 | 4.09 | 3.64 | 3.29 | 2.89 |
| 100 | 0.19 | 12.05 | L(m) | 5.76 | 5.02 | 4.47 | 4.05 | 3.56 |
| 120 | 0.16 | 12.84 | L(m) | 6.53 | 5.68 | 5.07 | 4.60 | 4.04 |
| 150 | 0.11 | 14.04 | L(m) | 7.56 | 6.58 | 5.87 | 5.32 | 4.68 |
| Note: 0.5mm outer steel sheet and 0.4mm inner steel sheet | ||||||||
| Allowable Span and Thermal Conductivity of Polyurethane Roof Sandwich Panel (allowable deformation f≤L/240) | ||||||||
|---|---|---|---|---|---|---|---|---|
| S(mm) | W/m2k | G(kg) | P=KN/m2 | 0.60 | 0.80 | 1.00 | 1.20 | 1.50 |
| 30 | 0.32 | 9.32 | L(m) | 2.60 | 2.30 | 2.08 | 1.91 | 1.72 |
| 50 | 0.31 | 10.15 | L(m) | 3.59 | 3.17 | 2.85 | 2.61 | 2.33 |
| 75 | 0.21 | 11.18 | L(m) | 4.64 | 4.07 | 3.66 | 3.34 | 2.96 |
| 100 | 0.19 | 12.22 | L(m) | 5.57 | 4.88 | 4.38 | 3.99 | 3.53 |
| 120 | 0.16 | 13.05 | L(m) | 6.28 | 5.49 | 4.92 | 4.48 | 3.97 |
| 150 | 0.11 | 14.30 | L(m) | 7.30 | 6.39 | 5.73 | 5.22 | 4.62 |
| Note: 0.5mm outer steel sheet and 0.4mm inner steel sheet | ||||||||
